Weight
2000H + Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.3 kg (7.3 lb)
2000R + “A” Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4 kg (3.1 lb)
Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.2 kg (11.3 lb)
Operating/Storage Conditions
Operating Temperature
Celsius . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0°C to 50°C
Fahrenheit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32°F to 122°F
Storage Temperature
Celsius . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -17°C to 75°C
Fahrenheit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0°F to 167°F
5. MAINTENANCE
The only service required for maintaining proper operation is the periodic
replacement of the battery in the receiver.
A. Connecting the Transmitter Battery
IMPORTANT:The battery is already installed in the 2000H Transmitter,
but is not connected until the fuse and fuse holder cap are installed.
1. While holding the fuse holder cap, insert the fuse barrel into the opening
on the left side of the transmitter.
2. Turn the fuse holder cap until secure.
3. Charge the transmitter battery before storing the unit. Never allow the unit
to sit for any length of time with a low or discharged battery.
B. Replacing the Receiver Battery
1. Remove the two screws on either side of the 2000R Receiver.
2. Separate the case and replace the 9 volt battery. Observe polarity.
3. Re-assemble the case and re-install the screws.
Do not overtighten the screws.
C. Cleaning
Periodically wipe with a damp cloth and mild detergent; do not use abrasives
or solvents.
7
Before opening the case, remove the test leads from the circuit and shut off
the unit.
Failure to observe this warning can result in severe injury or death.
WARNING
