Technical data
Characteristics AD800E
Process air flow
800 m
3
/h
Static pressure
150 Pascal
Reactivation air flow
250 m
3
/h
Static pressure
150 Pascal
Dehumidification capacity: @ 20°C ÷ 60% RH
4,4 Kg/h
Maximum input power
6,9 kW
Power supply Volt/Ph/Hz
400/3/50
Auxiliary power
24 V
Connection Outlet Process Air
 = 200 mm
Connection Inlet Process Air
 = 250 mm
Connection Outlet Wet Air
 = 160 mm
Connection Inlet Reactivation Air
 = 160 mm
Weight
145 kg
Total sound pressure (*):
72 dB (A)
(*) Sound pressure level calculated in free field, 10 meters from the unit, directional factor Q = 2 according to ISO 9614
Note:
For performance to different conditions - contact TFT srl for selection
Dimensions
PA = Inlet process air - DA = Outlet dry air - WA = Outlet wet air - RA = Inlet reactivation air
