AD800E-STD.EN-06 - Subject to change without notice TFT DryAir
Menu
Parameter
Description
Unit of
measurement
Default
Value
Set
Value
rC08
Setting cycle time for PWM control
10/sec
5,0
rC09
Setting time delay start regulation 3 points from the request (allows the
adjustment of the adjustment with the times of operation of the burner)
Sec
30
rC10
Setting set-delta temperature for over temperature mode adjustment 3 points
for burner (set-point reactivation [RC01] + set-delta [RC10]> Reactivation
temperature, the output of the burner control goes OFF)
°C
10,0
rC11
Setting time delay insertion electric heaters of reactivation to request activation
in control mode mixed steam/water + electricity (With CF02> 7). If the value is 0,
the function is disabled:
Min
0
CF--
CF01
Parameters selection on the display:
0 = Status
1 = Reactivation Temperature
2 = Probe input % relative or absolute humidity or DewPoint
3 = DewPoint value calculated (with RH% probe + post-treatment temp.)
4 = Absoluted humidity value calculated (with probe RH% + post-treatment
temp.)
5 = Temperature of pre-treatment (if any probe)
6 = Temperature of post-treatment (if any probe)
Num.
1
CF02
Reactivation type:
0 = No
1 = Electric first step (step 1)
2 = Electrical second step (2 steps)
3 = Electrical third step (3 steps)
4 = Electrical PWM control
5 = Steam (PWM control with converter)
6 = Throttle adjustment with 3 points
7 = Gas adjustable on / off (on / off burner, reg. High heat, low heat)
8 = Steam / Water proportional + Electric first step (step 1)
9 = Steam / Water proportional + Electric second step (2 steps)
10 = Steam / Water proportional + Electric third step (3 steps)
11 = Steam/Water proportional + Electric command PWM
Num.
1
CF03
Type adjusting pre-treatment:
0 = No
1 = Cooling
2 = Heating
Num.
0
CF04
Type adjusting post-treatment:
0 = No
1 = Cooling
2 = Heating
Num.
0
CF05
(*) Type control probe post-treatment:
0 = No
1 = NTC
Probe 2 = 4...20mA
Num.
0
CF06
(*) Setting the minimum value for probe post-treatment in version 4 ... 20mA
°C
-30,0
CF07
(*) Setting maximum value to probe post-treatment in version 4 ... 20mA
°C
70,0
CF08
(*)Type control probe Humidity/DewPoint 4 ... 20mA:
0 = No
1 = Relative humidity probe %
2 = probe DewPoint
3 = Probe Absolute humidity g/Kg
Num.
0
CF09
(*) Setting the minimum value for probe Humidity / DewPoint
%-°C-g/Kg
0,0
CF10
(*) Setting maximum value for humidity probe / DewPoint
%-°C-g/Kg
100,0
CF11
Type of reactivation probe:
0 = Probe NTC HT Eliwell
1 = Probe NTC HT Carel
2 = probe PT1000 (not available)
Num.
0
CF12
Control rotor is stationary:
OFF = Disable
On = Enable
OFF/On
On
CF13
Selection mode dehumidification control:
0 = from AIL4 analog input (Input 4…20mA)
1 = from Dewpoint Value calculated (with probe RH% + T)
2 = from absolute humidity value calculated (with probe RH% + T)
Num.
0
