5. ENGINE REMOVAL TGB
5-4
Loose the strap screw of engine left guide.
Remove the engine suspension nut and bolt ,
and then remove the engine.
Caution
Check if the engine suspension, rear shock
absorber bushing, and cushion rubber for
damage. Replace them with new ones if
so.
INSTALLATION OF ENGINE
Check if the bushings of engine suspension
frame and shock absorber for damaged. If so,
replace with new ones.
Install the engine according to the reversing
order of removal.
y With a bracket to support the engine to
prevent from it damage by falling down
as removing the engine.
Bushing
Strap screw of guide
Engine suspension nut
bolt
