The Singing Machine SML712BK - Location of Controls (Rear)

— E4 —
Location of Controls (Rear)
1. CDG Indicator
2. Display
3. Repeat Indicator
4. PLAY/PAUSE Indicator
5. Program Indicator
1. Video Out Jack
2. Mic Holder (side of unit)
3. Right/Left Audio Out Jacks
4. DC In Jack
5. Mic Holder (side of unit)
6. Battery Compartment
Location of Controls (Display)
4
5
1
3
2
CDG
REPEAT
PLAY/PAUSE
PROGRAM
u
w
y
v
x
U
