Thecus 8900 series User Manual

36
N4510U-R:
Back Panel
Item
Description
1.Power Connector
 Connect the included power cords to these connectors
2. WAN/LAN1 Port
 WAN/LAN1 port for connecting to an Ethernet network through a
switch or router
3. LAN2 Port
 LAN2 port for connecting to an Ethernet network through a switch
or router
4.USB Port
 USB 2.0 port for compatible USB devices, such as USB disks, and
USB printers
5.USB Port
 USB 2.0 port for compatible USB devices.
6.eSATA Port
 eSATA port for high-speed storage expansion
7.Line in
 For Audio in
8. Line out
 For Audio out
9. Mic input
 Microphone input
10.HDMI Port
 For Video/Audio out
11.VGA Port
 For Video out
12. Locator LED
 Identifies each NAS within a rack mount configuration.
N4510U-S:
The rear panel of the N4510U-S is similar to the N4510U-R, but with a single power
connector:
