Thecus N3200XXX Series User Manual

28
N5200XXX:
The N5200XXX rear panel features ports and connectors.
Back Panel
Item Description
1.WAN/LAN1 Port  WAN/LAN1 port for connecting to an Ethernet network through a
switch or a router.
2.LAN2 Port  LAN2 port for connecting to a local Ethernet network through a
switch or router.
3.Serial Port  This port is for an external UPS device.
4.eSATA Port  eSATA port for high-speed external storage expansion.
5.USB Port  USB 2.0 port for compatible USB devices, such as USB disks and
USB printers.
6.System Fan  System fan that exhausts heat from the unit.
7.Power Connector
 Connect the included power cord to this connector.
6
7
1
2
3
4
5
