Checking System Status
After making connections on the N7700 and powering up, check whether the system
status is normal or has trouble by observing indicators on the front panel and hard
disk trays.
System Status Normal
The system status is normal if:
1. The WAN and LAN LEDs glow
green (assuming both are
connected).
2. The Power LED on the Front Panel
glows blue.
3. The HDD Power LED on each HDD
tray glows blue (assuming all
disks are installed).
4. The default IP address of the WAN
port is 192.168.1.100 displayed
on LCD.
System Trouble
The system has trouble if:
1. System Busy LED glows red.
If the system has trouble, please refer to
Chapter 7: Troubleshooting.
WARNING
There are no user serviceable parts inside the N7700. Please contact your
17
