Page 29

LOWER LIMIT SWITCH ADJUSTMENT

The height of the snorkel top cap is visible when installed with

cooktops that have a higher cooking surface than Thermador.

1) Unplug the power cord

2) Remove the J-Box cover

3) Loosen the adjustment screw and raise the adjustment.

4) Tighten the adjustment screw.

NOTE: To prevent damage to any internal parts,

the snorkel should be in the raised position when

this adjustment is made.

Trouble Shooting

Adjustment Bracket

for lower limit switch

Adjustment Screw

for lower limit switch
