PAGE 7
STEP 7 -
INSTALL DRYWALL ON THE
SOFFIT
STEP 6 -
TURN THE POWER ON AND
CHECK HOOD OPERATION
Fig. 12
Chimney
Fig. 11
ADJUSTABLE CHIMNEY MOUNT-
ING STRUCTURES MAY BE
PURCHASED SEPARATELY IN
THE FOLLOWING SIZES:
Pro Island Chimney Assembly 9 to 15" PHICHIM15
Pro Island Chimney Assembly 15 to 27" PHICHIM27
Pro Island Chimney Assembly 27 to 51" PHICHIM51
