APPENDIX A-26 Manual 0-2962
APPENDIX 10: HAND TORCH WIRING DIAGRAMS
PIP
Switch
Torch
Switch
1
2
3
4
ATC Male
Connector
Orange
Black
Green
White
Torch Leads
Pilot
1
2
3
4
Torch Head
Pilot
Negative / Plasma
To Power Supply
Internal Connections
Power Supply
Adapter
Torch & Leads with O2B Connector
White
Black
Orange
Green
Power Supply
Front Panel
(Console)
Torch
Switch
SL60 - SL100 Hand Torch
Hand Torch and Leads with O2B Connector
Hand Torch and Leads with ATC Connector, Power Supply with ATC Adapter
PIP
Switch
Torch
Switch
1
2
3
4
ATC Male
Connector
ATC Female
Receptacle
Art # A-03679
Orange
Black
Green
White
Pilot
Negative / Plasma
Torch Head
White
Black
Orange
Green
Torch Head
Torch Leads
Pilot
Pilot
Power Supply
Bulkhead
Pilot
Power Supply
Bulkhead
Negative / Plasma
PIP
Switch
1
2
3
4
ATC Adapter Female
Receptacle
Negative / Plasma
Torch Leads
Negative / Plasma
Negative / Plasma
Hand Torch & Leads with ATC Connector,
Power Supply with Console - Mounted ATC Receptacle
Power Supply
Adapter
Torch & Leads with
ATC Connector
ATC Adapter
Assembly
Torch & Leads with
ATC Connector
Power Supply with
Console-Mounted
ATC Receptacle
