Operation Instructions
1. Turn on the circuit breaker to bring electrical power to the unit. The LED digital
display screen will light.
2. Turn on the water faucet for a few minutes until water ow is continuous and all air
is drained from water pipes. The unit must be operated after the breaker is turned on.
3. After the unit is supplied with power, please turn on the water and then the
appliance will start working. The minimum water ow to activate the unit is 1.5L/min.
4. If the water ow is turned o, the appliance will stop working. It is not necessary to
turn o the heater by pressing any key on front panel.
5. Press
to adjust the setting temperature between 30°C and -55°C. Temperature
setting will cycle among 30°C, -55°C, -30°C. By pressing the key once, the setting
temperature will go up 1°C. Only when the unit is working is the press key to be
used to adjust the temperature. The default setting temperature is 55°C.
6. Press
continuously for 3 seconds, the setting temperature will be circularly
setup among 38°C - 42°C -55°C - 42°C - 38°C.
7.
is the function key, If you need to install the unit upside down, Please press
and hold for 3 seconds, the temperature display Arabic numerals will rotate 180°.
8. There is overheat production function for the appliance, if the outlet temperature
reaches 65°C, the appliance will decrease the power level automatically, and only
after the hot water temperature drops to 53°C will the unit recover and work
normally. Should this occur, reduce the setting temperature.
9. There is real-time leakage detection function. If a leakage is detected by the unit, the
appliance will stop working automatically.
10. Please check hot water with hand before you taking a shower.
•
If the unit will not be used in winter, drain out water completely so that the
heater will not be frozen.
•
Please periodically clean inlet strainer and the shower to keep a free water ow.
Maintenance
Note: Do not attempt to repair this water heater yourself, call a qualied plumber for
assistance. Before maintenance takes place, the power supply needs to be shut o.
The ThermaQ Touch does not require any regular maintenance. However, to ensure
consistent water ow, it is recommended to complete the following.
1. Periodically remove scale and dirt that may build up at the aerator of the faucet or in
the shower head.
2. There is a built in lter screen at inlet connection which should be cleaned from
time to time. Please turn o the water ow before doing this.
Guarantee
Your ThermaQ water heater is guaranteed for a period of 12 months from the date of
purchase. The unit is only guaranteed if the water heater has been installed and maintained
in accordance with these instructions. Full guarantee information can be found at:
ThermaQ.co.uk/guarantee.
Trouble-Shooting
Excellence in Hot Water Technology.
10
11
ThermaQ Specification Hotline 01924 270847
PROBLEMS POSSIBLE CAUSES CORRECTIVE ACTIONS
Inlet and outlet
fittings leaking.
•
Fittings not tight.
•
Rubber washer worn-out.
•
Tighten fittings.
•
Change rubber washer.
LED no signal.
•
Power not connected.
•
LED Damaged.
•
Connect power to the unit.
•
Change LED.
Functional keys not
working.
•
No water out from shower.
•
Water pressure too low.
•
Key or PCB damaged.
•
Open valve to get water.
•
Open valve to get pressure.
•
Change key or PCB
Water too hot.
•
Too high temperature set.
•
Water flow too small.
•
Set a lower temperature.
•
Open valve bigger.
Water too cold.
•
Low temperature set.
•
Water flow too much.
•
Set a higher temperature.
•
Reduce water flow.
Outlet water volume
gets smaller and
smaller.
•
Inlet strainer or shower clogged.
•
Clean strainer and shower.
ITEM UNIT QUANTITY
Electric Water Heater. Unit 1
Bracket. Piece 1
Rubber plug and screw. Piece 1
Operation and Installation instructions. Copy 1
Cable Clamp and Screw Sets. Set 1
PACKING
LIST
