Thermo King CSR-20 Series User Manual

CSR-20 & CSR-40, September 1999
Introduction CSR Features vii
CSR Model Features (Continued)
XXXXXXXXX 460-380V/3Ph/60-50 Hz, 18.3 m (60 ft) Power Cable and Plug
––––––––– Dual Voltage Feature: 15 kVA Autotransformer with 460-380V Power Receptacle and 230-
190V/3Ph/60-50 Hz, 18.3 m (60 ft) Power Cable and Plug
XXXXXXXXX Automatic Phase Selection Control
XXXXXXXXX 25 Amp Main Power Circuit Breaker
– – X X – – – – X Slimline Frame
XXXXXXXXX Hermetic Scroll Compressor w/4.48 kW (6.0 Hp) Motor
XXXXXXXXX Hermetic Refrigeration System
XXXXXXXXX Compressor Liquid Injection System
XXXXXXXXX Warm Gas Bypass Valve System
XXXXXXXXX Modulation Valve
XXXXXXXXX Refrigerant R-404A w/Polyol Ester Compressor Oil (TK P/N 203-433)
XXXXXXXXX Receiver Tank
XXXXXXXXX µP-D Controller with Proportional-integral Differential (PID) Capacity Control
XXXXXXXXX Controller Emergency Bypass Module
XXXXXXXXX USDA Cold Treatment Temperature Recording
– – X X – – – – X Three Evaporator Fans with 2-Speed Motors
X X – – X X X X – Two Evaporator Fans with 2-Speed Motors
XXXXXXXXX Fresh Air Exchange System
XXXXXXXXX CO
2
Sampling Port
XXXXXXXXX One 1-Speed Condenser Fan Motor
–– XXXX––– Auxiliary Battery and Battery Charger
––––––––– Bulb Mode Operation
––––––––– Controlled Atmosphere System
XXXXXXXXX Data Retrieval Receptacle, Standard (5-Pin Duetsch)
––––––––– Data Retrieval Receptacle, 5-Pin Threaded Cannon
––––––––– Data Retrieval Receptacle, 15-Pin RS232
X – X – X – – – – Dehumidify Control
– – X X – – – – – Humidity System
––––––––– Power Line Communications, Standard (Thermo King Modem)
––––––––– Power Line Communications, Thermo King Integrated Remote Monitor Unit (IRMU)
––––––––– Power Line Communications, RTE Modem
– – X X – – – – – Power Line Communications, Sabroe Control Modem
–––––X––– Recorder, Partlow
–X–––––XX Recorder, Saginomiya
––––––––– Redundant Supply and Return Sensors
– – – – X X – – – Remote Monitoring Plug (4-Pin)
– – – – X – – – – TRANSFRESH
®
Provision
––––––––– TRANSFRESH
®
Purge Port
– – X X – – – – – TRANSFRESH
®
System, Complete
– – – – X X – – – Thermistor Lead
––––––X–– Water-Cooled Condenser-Receiver Tank
CSR-40-128 CSR-40-129 CSR-40SL-130 CSR-20SL-131 CSR-40-134 CSR-40-136 CSR-40-139 CSR-40-140 CSR-40SL-142
FEATURES
X = Included
MODEL

Thermo King CSR-20 Series Specifications

General

Brand	Thermo King
Model	CSR-20 Series
Category	Heat Pump
Language	English
