- 6 -
Section III InstallationSection III Installation
Section III InstallationSection III Installation
Section III Installation
SiteSite
SiteSite
Site
The unit should be located in a laboratory or clean industrial environment
where ambient temperatures are inside the range of +55°F to +95°F (+13°C
to +35°C).
Never place the unit in a location where excessive heat, moisture, orNever place the unit in a location where excessive heat, moisture, or
Never place the unit in a location where excessive heat, moisture, orNever place the unit in a location where excessive heat, moisture, or
Never place the unit in a location where excessive heat, moisture, or
corrosive materials are present.corrosive materials are present.
corrosive materials are present.corrosive materials are present.
corrosive materials are present.
The unit has an air-cooled refrigeration system. On the CC-65 air is drawn
through the top of the unit and discharged through the sides and bottom of
the unit. On the CC-100 air is drawn through the front of the unit and dis-
charged through the rear. The unit must be positioned so the intake and
discharge are not impeded. A minimum clearance of 12 inches (30 centi-
meters) on all vented sides is necessary for adequate ventilation.
Inadequate ventilation will cause a reduction in cooling capacity and, in
extreme cases, compressor failure.
Excessively dusty areas should be avoided and a periodic cleaning schedule
should be instituted (see Section V, Cleaning).
The unit will retain its full rated capacity in ambient temperatures up to
approximately +75°F (+24°C). Above +75°F, reduce the cooling capacity 1%
for every 1°F above +75°F, up to a maximum ambient temperature of +95°F.
In terms of Celsius, reduce the cooling capacity 1% for every 0.5°C above
+24°C, up to a maximum ambient temperature of +35°C.
ElectricalElectrical
ElectricalElectrical
Electrical
RequirementsRequirements
RequirementsRequirements
Requirements
Refer to the serial number label on the rear of the unit for the specific
electrical requirements of your unit.
Make sure the voltage of the power source meets the specified voltage, ±10%.
Make sure an adequate ground connection is provided.Make sure an adequate ground connection is provided.
Make sure an adequate ground connection is provided.Make sure an adequate ground connection is provided.
Make sure an adequate ground connection is provided.
