ThermoFlow Elex 21 - Page 11

Electric Tankless Instant Water Heater - Installation Manual and User Guide
11
EN
Mounting Instructions
Elex 6/8/8.5/9.6/10/12/15/18/21/24/3IN1 (P)
B1.
1
B1.
2
B2.
B2.
2
1
Display plug
B3.
B3.
MOUNTING TEMPLATE
Minimum distance from wall Minimum distance from wall
Warm water connection Cold water connection
Minimum distance to the ground
Minimum distance to the ceiling
Connection to wall Connection to wall
Input electric cable
Screws, washers and anchors
5/16”
5/16”
5/16”
4”
8”
4”
4”
5/16”
Rev02 NA
B4.
B4.
100mm(4”)
50mm(2”)
pipe wall
pipe wall
Don’t over-tighten the connections!
Use a spanner!
Max 18 Nm
Arrow on the inlet connector
must be installed outward from
the wall!
