19
Technical Manual
© 2006 by Thermoplan, Subject to change
Tiger REV-8
SECTION 3Menu 8
In this menu you can set the machine parameters.
By pressing the enter key you access the menu.
8 Mach Parameters
8-1 Boiler Temp
092 °C
In menu 8-1 you can set the desired water temperature in the boiler with the Plus-/Minus levers. Range is between 60
and 105 °C.
8-3 Over Temp
05 °C
In menu 8-3 you can set the overheat temperature of the boiler with the Plus-/Minus levers. 5 minutes after the last
dispensed coffee product this function heats up the boiler by the programmed value over the standard temperature to
prevent the loss of temperature. The range is between 0 and 15 °C.
8-4 Pump Rot Coffee
1200 RPM
In menu 8-4 you can adjust the speed of the pump rotation for coffee products.
8-5 Pump Rot Tea
0700 RPM
In menu 8-5 you can adjust the speed of the pump rotation for the tea.
8-6 Milk Pump Temp
0085 °C
In menu 8-6 you can set the milk pump temperature on the thermoblock with the Plus-/Minus levers. This temperature
is the release for the milk pump. Range is between 20 and 140 °C.
8-7 Milk Temp
0095 °C
In menu 8-7 you can set the milk temperature of the NTC on the thermoblock. Range is between 20 and 140 °C.
8-8 Foam Pump Temp
0085 °C
In menu 8-8 you can set the milk foam pump temperature on the thermoblock with the Plus-/Minus levers. This tem-
perature is the release for the milk pump. Range is between 20 and 140 °C.
8-9 Foam Temp
0095 °C
In menu 8-9 you can set the milk foam temperature of the NTC on the thermoblock. Range is between 20 and 140
°C.
8-10 Pump Rot Milk
0700 RPM
In menu 8-10 you can adjust the speed of the pump rotation for the milk.
8-11 Pump Rot Foam
1350 RPM
In menu 8-11 you can adjust the speed of the pump rotation for milk foam products.
