14
Technical Manual
© 2006 by Thermoplan, Subject to change
Tiger REV-8
SECTION 3Menu 6
6 Machine Function
6-1 Machine Type
CTM
6-3 Kbd. Menu Access
As technician
6-4 Operating Mode
In menu 6-4 you can set the operating mode
Self-Service:
Machine is set to Self-Service mode
Standard: Additionally you can free-switch or cloesed the individual options with the
Menus 6-5 until 6-10.
In this menu you can read and adjust several machine function.
Press the enter key to access the menu.
In menu 6-1 you can set the machine typ with the Plus-/Minus lever.
C = Coffee CT = Coffee Tea
CTM = Coffee Tea Milk CTS = Coffee Tea Steam
6-2 Key Selection
In menu 6-2 you can adjust the key selection as follow:
- Milk coffee product oder Coffe product / - Grind left oder Grind right / - Adjust of the key names.
Im Menü 6-2 you can set the desired key with the Plus-/Minus levers.
6-2 Key 1
1x Coffee
<- Grinder
Coffee
Example of a programming of the Key 1:
1.Press a product key for exampel „Coffee“.
2. With this Plus-/Minus levers you can set the product of the key 1.
Mögliche Einstellungen:
3. With the Stop key you can saved the settings.
4. Repeat the same process for adjust the next products.
6-2 Key Selection
Select key
Product key
You can set the key selection with the Plus-/Minus levers.
Enter key
Coffee
6-2 Key 1
1x Coffee
<- Grinder
Coffee
1x = Single product
2x = Double product
Select the product type
Select the grinders:
<- Grinder = Grinder left
Grinder -> = Grinder right
<-> Grinder = Grinder left/right
Select the product name
Im Menü 6-3 you can activate the Operator- or the Technician mode.
In the standard-settings are the key combination for the entry in the programming level closed.
For the entry in the programming level are a Tiger Service Master Card necessary.
Note: Mode „As Operator“ = Programming level only for the Operator
Mode „As Technician“ = Programming level for Technician and Operator
