Technical Manual
© 2006 by Thermoplan, Subject to change
Tiger REV-8
SECTION 3Overview Programming menues
1 Lernmodus
SL Operator
9 Masch Unterhalt
SL Operator
6 Machine Function
SL Technician
6-1 Machine Type
SL Technician
6-2 Key Selection
SL Technician
6-3 Kbd. Menu Access
SL Technician
7 Mach Maintenance
SL Technician
7-1 Time-Date
SL Technician
7-2 Language
SL Technician
7-3 Temp. Unit
SL Technician
6-4 Operating Mode
SL Technician
6-5 Double Products
SL Technician
6-6 POD Products
SL Technician
6-7 Rinse Key
SL Technician
6-8 Grinder Key
SL Technician
6-9 Milksort Key
SL Technician
6-11 Mains Voltage
SL Technician
6-13 Water Source
SL Technician
6-15 Sens Drip Tray
SL Technician
6-16 Numb Grinders
SL Technician
6-17 Milk Source
SL Technician
6-20 Cold Milk
SL Technician
6-21 Purge Aktiv
SL Technician
6-23 Cup Heater
SL Technician
6-24 Interface Option
SL Technician
6-25 Currency
SL Technician
7-5 Grind Capcty ->
SL Technician
7-6 <- Grind Capcty
SL Technician
7-7 Display Contrast
SL Technician
7-9 Service Interval
SL Technician
7-10 Service Date
SL Technician
7-11 Coffee Quantitiy
SL Technician
7-12 Filter Water
SL Technician
7-13 Filter Wat. Date
SL Technician
7-14 Grounds
SL Technician
7-15 Drawer Time
SL Technician
7-18 Cleaning
SL Technician
7-20 Cleaning Period
SL Technician
7-21 Cleaning Time
SL Technician
7-23 Clean Labyrinth
SL Technician
7-24 Preheating Activ
SL Technician
1 Lernmodus
SL Operator
7-29 CPU -> EEPROM
SL Technician
7-30 EEPROM -> CPU
SL Technician
6-22 NTC Steam pipe
SL Technician
6-26 Reed Thermoblock
SL Technician
6-27 Light barrier
SL Technician
6-28 Ventilator Ctrl
SL Technician
