Place heat tents over burners by inserting tabs into slots in front of firebox.
Opposite ends of heat tents rest on pins in back of firebox.
Heat Tent
Back of Firebox
Pin
Heat Tent
Front of Firebox
Place cooking grates onto grate rests.
Unscrew ignitor cap and place AA battery into ignitor slot with positive end (+) facing outward. Replace ignitor cap onto ignitor.
11
12
AA Battery
Cooking Grate
-
+
