Thermos 463322012 - Assembly

ASSEMBLY
1/4 -20x1-1/2"
Machine Screw
"
Qty: 4
Place bottom shelf with cut out hole for LP tank next to legs with axle holes.
Attach to right and left leg assemblies with 1/4 -20x1-1/2" screws and 1/4 -20 flange nuts." "
Axle Hole
Bottom Shelf
1
2
1/4 -20
Flange Nut
"
Qty: 4
17
Right Leg Assembly
Left Leg Assembly
Attach front panel to cart with #8x3/8" sheet metal screws.
Front Panel
Sheet Metal Screw
Qty. 6
#8x3/8"
