Thermowave TL850 - User Manual

thermowave
Gesellschaft für Wärmetechnik mbH
Eichenweg 4
06536 Berga
Telefon: +49 34651 418 0
Fax: +49 34651 418 13
E-mail: info@thermowave.de
Web: www.thermowave.de
BA EN 12.2019 Modification 02 from 01.12.19. Copies are not subject to the change service.
Manual
Plate heat exchanger
Type:
ID number:
Order number:
Position:
Project:

Summary

Important basic information

Following the operating instructions

Please read the operating instructions thoroughly and in full.

Safety

Depiction of information

Defines DANGER, WARNING, CAUTION, and NOTICE for hazards and material damage.

Intended use of the PHE

PHE must be installed, activated, operated, repaired by instructed, trained, qualified, skilled personnel.

Safety-relevant instructions for specific life phases

Possible misuse

Delivery, transport, installation

Transport

DANGER: Mortal danger using wrong lifting means; use undamaged round slings, not steel ropes/chains.

Installing the apparatus at the installation site

WARNING: Risk of injury due to lack of stability and height; use safety helmet, clothing, and suitable lifting means.

Horizontal delivery - On the side

Horizontal delivery - On the head plate

Vertical delivery

DANGER: Tipping over; falling down if lifting means are incorrect. Anchor PHE before undoing lifting means.

Vertical delivery with base of the apparatus

Connection, activation and shutdown

Connection

DANGER: Tipping over risk. Anchor PHE firmly. Ensure sufficient space and flexible pipes.

Activation

WARNING: Risk of injury from dangerous mediums. Ensure proper safety devices and gradual pressure/temperature changes.

Shutdown

Operations

Troubleshooting

Performance loss

Details causes and remedies for reduced heat transfer and heightened loss of pressure.

Lack of leak-tightness

Lists causes and remedies for mediums escaping from plate packet or between frame and plates.

Maintenance, servicing and cleaning

Safety

WARNING: Risk of injury during maintenance. PHE must be inoperative; empty PHE; wear PPE.

Maintenance schedule

Replacing the gaskets

Instructions for replacing gaskets, recommending original parts and ensuring proper seating.

Repairing leakages

WARNING: Risk of injury due to leakages. Repair leaks promptly by an expert.

Opening and closing the plate packet

Closing the plate packet

Check plate order, push cover, place screws, tighten nuts sequentially to specified dimension.

Removal and installation of the plate packet

Installation of the heat exchanger plates

Cleaning

Cleaning the laser-welded modules

CIP cleaning (cleaning in place)

Manual cleaning

Disassembly and disposal

Disassembly

WARNING: Risk of injury. PHE must be inoperative; empty PHE; ensure ambient pressure/temperature; wear PPE.
