Manual
Plate heat exchanger
Type:
ID number:
Order number:
Position:
Project:

Table of Contents

Questions and Answers

  • T
    Thomas ToddAug 7, 2025
    What to do if my Thermowave Industrial Equipment is leaking?
    • J
      Jason LawsonAug 7, 2025
      If your Thermowave Industrial Equipment is leaking, several issues could be the cause. Begin by checking the name plate and order-related documents for correct specifications. Verify the operating temperature isn't too high or low. Ensure the tensioning dimension is correct using the name plate or order-related documents. Inspect the gaskets for contamination, damage, or incorrect seating. If issues persist, the heat exchanger plates may be damaged.
  • C
    Craig McdonaldAug 22, 2025
    Why is heat transfer reduced in my Thermowave Industrial Equipment?
    • P
      Phyllis ClarkAug 22, 2025
      Reduced heat transfer in your Thermowave Industrial Equipment can stem from several causes. The heat exchanger plates might be contaminated by foreign objects. The flow rate may be too high, so ensure it matches the order-related operating data. Check that the pipe connections are correct according to the diagram. Also, the accumulation of secondary mediums, such as oil or uncondensed gases, could be the problem; ensure there's a discharge facility for these.

Summary

Important Basic Information

Following the Operating Instructions

Ensuring all users read and understand the manual for safe and effective operation.

Responsibilities

Safety

Depiction of Information

Understanding warning notices, hazard levels, and writing styles used in the manual.

Intended Use of the PHE

Specifying the designed purpose and operating conditions for the plate heat exchanger.

Safety-Relevant Instructions for Specific Life Phases

Essential safety measures for transport, installation, operation, and disassembly.

Possible Misuse

Identifying and warning against improper uses of the plate heat exchanger.

Delivery, Transport, Installation

Transport

Installing the Apparatus at the Installation Site

General safety and procedural guidelines for positioning the PHE.

Horizontal Delivery - On the Side

Horizontal Delivery - On the Head Plate

Vertical Delivery

Vertical Delivery with Base of the Apparatus

Connection, Activation, and Shutdown

Connection

Guidelines and safety measures for connecting the PHE to the system.

Activation

Procedures and precautions for starting up the PHE for operation.

Shutdown

Reactivation After Shutdown

Operations

General

Troubleshooting

Performance Loss

Identification of causes and remedies for reduced heat transfer or increased pressure loss.

Lack of Leak-tightness

Troubleshooting guide for identifying and resolving issues related to leaks.

Maintenance, Servicing, and Cleaning

Safety

Critical safety precautions to be observed during maintenance activities.

Maintenance Schedule

Servicing Work

Repairing Leakages

Procedures and warnings for fixing leaks in the PHE.

Opening and Closing the Plate Packet

Step-by-step instructions for safely opening and reassembling the PHE.

Closing the Plate Packet

Procedure for properly reassembling the PHE plate packet after servicing.

Removal and Installation of the Plate Packet

Detailed steps for removing and installing PHE plate assemblies.

Cleaning

Cleaning Laser-Welded Modules

CIP Cleaning (In Place)

Manual Cleaning

Disassembly and Disposal

Disassembly

Disposal

Thermowave TL2000 Specifications

General IconGeneral
BrandThermowave
ModelTL2000
CategoryIndustrial Equipment
LanguageEnglish
