9
Gas Connection
Prior to connection ensure the local conditions for gas type and gas pressure match the
appliance specification. (Gas type and pressure for this appliance are printed on the databadge
located on the base of appliance)
The Ø8mm gas inlet is located to the rear of the appliance. Prior to connection remove the
plastic protection plug from the fitting. The appliance MUST be connected using metal pipe
manufactured from either copper, seam welded steel, seamless steel or stainless steel, which
complies to the requirements of EN1949, rubber tubing MUST NOT be used.
Electrical Connection
The fan cooling system and spark ignition generator MUST only be connected to a suitable 12v
DC supply. We recommend connection using sheathed spade connectors. To achieve
optimum performance from the fan cooling system a constant 12V supply is required.
This appliance needs little maintenance other than cleaning. All parts should be cleaned using
warm soapy water. Do not use abrasive cleaners, steel wool or cleansing powders. When
cleaning the burner ring it is essential to ensure that the holes do not become blocked. The
control knobs are a push fit and can be removed for cleaning. They are interchangeable
without affecting the sense of operation.
All servicing must be carried out by an approved competent person. After each service the
appliance must be checked for gas soundness. We recommend the appliance is serviced
every 12 months to maintain optimum performance.
If servicing requires removal of the appliance:- (1) Turn off gas, 12volt power supply and/or
240 volt supply, depending on model. (2) Disconnect appliance from gas and electrical supply.
(3) Disconnect the spark generator 12v supply. (4) Release and remove the fixing screws.
(5) Carefully lift out the appliance from the cabinet and place on a suitable surface.
After installation the appliance MUST be tested for soundness
• This appliance MUST be installed into an aperture, sealed off at either
side in order to prevent draughts from adjoining cupboards/vents. Ensure
that air vents and gas escape holes are kept clear, holes for cables and
pipes must be sized to minimize air leakage between compartments.
• When installing an appliance at ‘Eye’ level, any cupboards beneath the
appliance MUST be sealed to prevent a gas escape entering the living
area.
• The gas supply pressure to which this appliance is connected MUST not
rise or fall by more than 2.5mbar from nominal, when all appliances
connected to the supply are operated simultaneously.
