ThinkPad T440p - Page 92

4
5
5
6
Wheninstalling:
Ensurethattheconnectorsarefirmlyattachedandyouroutethecablesfirmlyandtapeupintheproper
positions.
Attention:Whenyouroutethecables,ensurethattheyarenotsubjecttoanytension.Tensioncouldcause
thecablestobedamagedbythecableguides,orawiretobebroken.
7
8
7
8
StepScrew(quantity)Color
Torque
7
M2.5×8mm,flat-head,nylon-coated(2)
Black0.392Nm
(4.0kgf-cm)
8
M2×3mm,flat-head,nylon-coated(2)
Black0.181Nm
(1.85kgf-cm)
86HardwareMaintenanceManual
