Chapter 3. Reference Information 3-1
Chapter 3 Reference information
This section contains monitor specifications, instructions to manually install the monitor driver,
troubleshooting information, and service information.
Monitor specifications
Table 3-1. Monitor specifications for type-model 60B8-AAR6-WW
Dimensions Height
Depth
Width
341.5 mm (13.44 in.)
167.2 mm (6.58 in.)
448.40 mm (17.65 in.)
Stand
Tilt range Range: -5°/+20°
VESA mount Supported 100 mm (3.94 in.)
Viewable image size
Maximum height
Maximum width
Pixel pitch
470.1 mm (18.51 in.)
230.40 mm (9.07 in.)
409.80 mm (16.13 in.)
0.3 mm (0.010 in.) (V)
Power input Supply voltage
Max supply
current
100-240 VAC, 60/50 Hz
1.0 A
Power consumption
Note: Power consumption figures
are for the monitor and the power
supply combined.
Max Consumption
(Without USB hub)
Typical Consumption
Standby/Suspend
Off
17W
13.7 W
≦0.5 W
≦0.5W
Video input (Analog) Input signal
Horizontal addressability
Vertical addressability
Clock frequency
Analog Direct Drive, 75 ohm
0.7 V
1366 pixels (max)
768 lines (max)
85.5 MHz
Communications VESA DDC CI
Altitude Test Operation 6561.68 ft
Supported Display Modes
(VESA Standard modes
between noted ranges)
Horizontal frequency
Vertical frequency
Native Resolution
VGA: 30 kHz – 83 kHz
50 Hz – 75 Hz
1366 x 768 at 60 Hz
Temperature Operating
Storage
Shipping
0° to 40°C (32°F to 104° F)
-20° to 60°C (-4°F to 140° F)
-20° to 60°C (-4° F to 140° F)
Humidity Operating
Storage
Shipping
20% to 90%
10% to 90%
10% to 90%
