Contents
1. Introduction 1-1
1-1 Acknowledgment ---------------------------------------------------------------------- 1-1
1-
2 About this manual --------------------------------------------------------------------- 1-1
1-
3 Intended use --------------------------------------------------------------------------- 1-2
1-
4 About product support ---------------------------------------------------------------- 1-2
1-
5 Product and company information --------------------------------------------------- 1-2
2. Precautions on Use 2-1
2-1 Safety Related Warning Displays ---------------------------------------------------- 2-1
2-
2 Transportation and Storage ---------------------------------------------------------- 2-1
2-
3 Mounting and Installation ------------------------------------------------------------- 2-2
2-
4 Operation ------------------------------------------------------------------------------ 2-2
2-
5 Lubrication and Maintenance -------------------------------------------------------- 2-3
3. Marking on the Master Rail and Combined Use
3-1
4. About Product 4-1
4-1 System configuration ----------------------------------------------------------------- 4-1
4-
2 Product Specifications ---------------------------------------------------------------- 4-2
5. Mounting 5-1
6. Permissible Error of the Mounting Surface 6-1
7. Cables and Wiring 7-1
7-1 Wiring ---------------------------------------------------------------------------------- 7-1
7-
2 Minimum bending radius ------------------------------------------------------------- 7-2
8. Lubrication 8-1
9. Troubleshooting 9-1
10.
Appendix 10-1
10-1 Resolution Check -------------------------------------------------------------------- 10-1
10-2
Effective Stroke ----------------------------------------------------------------------- 10-1
10-3
Standard Length and Maximum Length -------------------------------------------- 10-2
