thomann DSP 26 User Manual

This menu is used to select the operating mode. In the [UTILITY] menu, select the ‘System
Utilities’ option and confirm with [ENTER].
Select the ‘System Setup’ menu item and confirm with [ENTER]. The active operating mode is
shown on the display.
Select the required operating mode with [PM2] or [PM3] and confirm by pressing [ENTER] to
apply the new setting.
Operating modes
n ‘2 × 2 WAY + SUB’ – in this operating mode, two inputs are assigned to four outputs as
follows:
– Input A to output 1/3 (1 = Low-A, 3 = High-A)
– Input B to output 2/4 (2 = Low-B, 4 = High-B)
– Input A and B to output 5/6 (5 = Sub-A, 6 = Sub-B)
n ‘2 × 3 WAY.XOVER’ – in this operating mode, two inputs are assigned to six outputs as fol‐
lows:
– Input A to output 1/3/5 (1 = Low-A, 3 = Mid-A, 5 = High-A)
– Input B to output 2/4/6 (2 = Low-B, 4 = Mid-B, 6 = High-B)
n ‘6 WAY.XOVER’ – in this operating mode, input A is assigned to six outputs as follows:
– Input A to output 1/2/3/4/5/6 (1 = Near-1, 2 = Near-2, 3 = Mid-1, 4 = Mid-2, 5 = Far-1, 6
= Far-2)
"System Utilities" – "System
Setup"
Operating
digital speaker management system
24
