thomann DSP 26 User Manual

This menu is used to lower or raise the level of the output signal on a per channel basis in a
range of –12 dB to +12 dB. Press [1], [2], [3], [4], [5] and/or [6], to activate the edit mode.
Use [PM2] or [PM3] to adjust the level of the output signal as required. Confirm the new setting
with [ENTER].
Pressing [ESC] exits the menu without applying changes.
This menu is used to adjust the limiter function settings on a per channel basis. Press [1], [2],
[3], [4], [5] and/or [6], to activate the edit mode and adjust the following parameters as
required:
n Response time with [NAV/PM1], range ‘5 ms’ … ‘200 ms’
n Ramp-down time with [PM2], range ‘5 ms’ … ‘200 ms’
n Threshold with [PM3], range ‘–10 dB’ … ‘
+ 20 dB’
Pressing [ESC] exits the menu without applying changes.
"Gain"
"Limiter"
Operating
digital speaker management system
44
