8 Rotary control [–] / [+]
Increases or decreases the value of the currently selected parameter.
9 Fader S1 … S6 for the connected pads, function depends on selection [ALTER] (10)
10 [ALTER]
Selector switch for faders function S1 … S6: Volume, FX or MIDI. The control LED of the enabled function lights up.
11 [KIT]
[PATTERN]
[EDIT]
[SETUP]
[MODE]
[METRO]
Button to activate ‘Kit’ mode.
Button to activate ‘Pattern’ mode.
Button to open the programming menu.
Button to open the device settings menu.
Button to switch between operating modes.
Turns the metronome on and off and opens the click menu.
12 [DRUM]
Button to mute the Drum track of a style.
13 [ACCOMP]
Button to mute the Accompaniment track of a style.
Connections and controls
e-drum module
20
