1. Press the [EDIT] button corresponding to the desired channel.
ð
The settings menu for the desired channel opens up. The display shows
‘GAIN’ .
2. In the default state of the menu, you can adjust the channel level in a range of
-60 dB…+12 dB with the rotary switch.
3. To set additional parameters of the channel, press the corresponding button.
Use the rotary switch to set the desired value of the parameter. Press the rotary
switch to conrm.
The table below shows the available parameters and their value ranges.
Parameter Button Selection range Meaning
‘PHASE’ [GAIN] ‘0’ , ‘180’ Phase reverse
‘IIR’ [X-OVER] ‘HP’ : ‘20Hz’ … ‘20kHz’
‘LP’ : ‘20Hz’ … ‘20kHz’
‘BUTTER-xx’ (Butterworth), ‘BESSEL-xx’
(Bessel), ‘LINK/R-xx’ (Linkwitz-Riley)
Slope: ‘–6dB/oct’ … ‘–48dB/oct’
IIR lter. Digital high and low pass lter parame‐
ters: Cut-o frequency, lter type and slope
‘FIR’ [X-OVER] ‘T’ : ‘256’ … ‘1024’
‘W’
‘BY’
‘HP’ : ‘150Hz’ … ‘20kHz’
‘LP’ : ‘150Hz’ … ‘20kHz’
FIR lter. Number of FIR taps, FIR lter frequency
response, bypass, cut-o frequencies for digital
high-pass and low-pass
‘DELAY’ [DELAY] ‘0ms’ … ‘680ms’
‘0m’ … ‘234m’
‘0ft’ … ‘766ft’
Delay time. The displayed unit depends on the
basic setting of the device.
‘OUT-LINK’ [DELAY] The settings of several input channels can be
linked together. If the current channel is ‘OUT1’ ,
you can select ‘OUT2’ … ‘OUT8’ to change the
parameters simultaneously.
‘FEQ’ [PEQ] ‘FEQ’ : ‘1’ … ‘9’
‘G’ : ‘–12dB’ … ‘+12dB’
‘FREQ’ : ‘20Hz’ … ‘20kHz’
‘Q’ : ‘0.4’ … ‘128’
‘Style’ : ‘PEAK’ , ‘L-SHLF’ , ‘H-SHLF’ , ‘LCUT’ ,
‘HCUT’ , ‘A-PAS1’ , ‘A-PAS2’ and ‘BP’
For 9 frequency bands (numbered with the
parameter ‘FEQ’ ) you can set the parameters of
the parametric equalizer: Centre frequency, lter
quality, slew rate, lter type, on or o (bypass).
Settings for the outputs
Operating on the unit
digital speaker management system
16
