6 Operating on the unit
Connect the device to the power grid and turn it on with the main switch to start
operation. After a few seconds, the display indicates that a reset is in progress. The
device is then ready for use. The display shows the model name and user preset cur‐
rently active.
The device can only be operated directly with the buttons if it is not controlled via
USB, LAN or the serial interface.
The currently usable buttons light up permanently, the last used ones ash. Currently
unavailable buttons remain unlit.
1. Press [UTIL] repeatedly until the desired parameter appears in the display.
The table below shows the available parameters and their value ranges.
2. Use the rotary switch to set the desired value of the parameter. Press the rotary
switch to conrm.
3. Press [EXIT].
Parameter Selection range Meaning
‘ID Number Select’ ‘1’ … ‘254’ Unique identication of the device in a series connection. If
multiple devices are connected in series, each must have a
unique number.
‘Manual IP Set’ If the device is integrated in a local network, its IP address can
be set individually. The initial IP address is 192.168.1.101.
‘Input Select’ ‘ANALOG’ Analogue input
‘AES / EBU’ Digital input
‘Output Select’ ‘ANALOG’ Analogue output
‘AES / EBU’ Digital output
‘Unit Lock PassWord’ ‘0000’ … ‘ZZZZ’ Four-digit device password. Any combination of numbers and
letters is adjustable. The initial password is 1234.
‘In Source Select’ ‘ANALOG INPUT’ , ‘PINK NOISE’ ,
‘WHITE NOISE’ , ‘SINE xx’
Signal source selection: Either the analogue inputs or the
internal test tone generator. The test tone generator optionally
generates: Pink noise, white noise or a sine wave 20 Hz…
20 kHz.
‘Copy CH select’ Transferring settings from one channel to another.
‘LCD DISPLAY TIME’ Setting the backlight duration: Max. 200 ms
Starting the device
Default settings
Operating on the unit
FIR DSP 408
13
