The TRS inputs of the amplifier are only suitable for mono operation. The following drawings
and tables indicate the pin assignment of a 1/4" phone plug to be used.
Balanced wiring:
1 (Tip) Positive signal (+)
2 (Ring) Negative signal (–)
3 (Sleeve) Ground, shielding
Unbalanced wiring:
1 Signal
2, 3 Ground, shielding
1/4" phone sockets for signal
inputs
Installation and starting up
TA 450 MK-X TA 600 MK-X TA 1050 MK-X TA 1400 MK-X TA 2400 MK-X
15
