DSP 4×4 Amp 4.250

8 Connection for the power cable

9 Screw terminal strip for switching the presets. The relevant preset is called up through potential-free bridging of pins

[Gnd] and [U01]…[U03] for 2 seconds.

10 Switch to toggle the supply voltage

11 [AMP OUT] | Outputs [CH1]…[CH4], designed as Speaker Twist

12 [PRE OUT] | Outputs [1]…[4], designed as 6.35 mm (1/4-inch) jack sockets (mono, balanced)

13 [INPUT] | Inputs [CH1]…[CH4], designed as XLR (mono, balanced)

Back

Connections and controls

DSP 4x4 Amp 4.250, DSP 4x4 Amp100V
