Operating instructions
= On/Off
= Select mode
CLEAR/HOLD = Zeroes/clear/freeze
START/STOP = Record/print out data
SETUP = Configure
SELECT-/+ = Settings
ADJUST-/+ = Adjust
! LCD matrix display
" Combined humidity/temperature
sensor connection
# Temperature sensor connection
$ Plug-in mains supply unit connection
% RS 232 interface connection
Important!
Please note warning symbol in the
operating instruction.
Copyright (c) by REVUE THOMMEN AG.
The contents of this publication may not be
copied without the express permission of
REVUE THOMMEN AG. Subject to dimension
and design changes.
EC Declaration of conformity
We declare on our own responsibility that this
product conforms to the following standards:
EN 50081-1 / EN 50082-1
