Thomson Power Systems TSC 900 User Manual

TS 970 Transfer Switch
PM163 REV 0 20/02/05 9 Thomson Power Systems
Anchoring Notes:
1. Anchoring must be designed according to IBC 2012 or latest version.
2. The anchoring details shown are recommended according to the seismic
certification; design Engineer may use alternate anchors within the scope of IBC.
3. Wall anchors in concrete; use a typical concrete anchor as necessary.
4. Expansion anchors as shown. To be installed according to manufacturer's
recommendation.
5. The 600-1200A NEMA 3R ATS enclosure is free standing (floor mounted only); If
free standing it must be a minimum of 12" (305mm) away from pipes, conduits or other
obstructions to allow for sway during a seismic event.

Thomson Power Systems TSC 900 Specifications

General

Brand	Thomson Power Systems
Model	TSC 900
Category	Switch
Language	English
