Thomson Power Systems TSC 900 User Manual

TS 970 Transfer Switch
PM163 REV 0 20/02/05 1 Thomson Power Systems
TABLE OF CONTENTS
1. PRODUCT REVISION HISTORY 3
2. EQUIPMENT STORAGE 3
2.1. ENVIRONMENTAL CONDITIONS 3
3. NOTES TO INSTALLER 4
3.1. INSTALLATION CODES/PERMITS 4
3.2. APPLICATION 4
3.3. INSTALLATION LOCATION 4
3.4. POWER CABLING 5
3.5. CONTROL WIRING 5
3.6. GENERATOR SET AUTOMATIC OPERATION 5
3.7. LOAD TYPES 5
3.8. UPSTREAM OVER CURRENT PROTECTION 5
3.9. WITHSTAND/INTERRUPTING CURRENT RATINGS 6
3.10. TRANSFER SWITCHES WITH MULTI-TAP VOLTAGE CAPABILITY 6
3.11. REMOTE START CONTACT FIELD WIRING 6
3.12. DIELECTRIC TESTING 7
3.13. SEISMIC ANCHORING 7
4. GENERAL DESCRIPTION 10
4.1. TSC 900 ATS CONTROLLER 10
4.2. POWER CONTACTOR ATS 11
4.3. PRODUCT MODEL CODE 12
4.4. TYPICAL COMMISSIONING PROCEDURES 13
5. AUTOMATIC SEQUENCE OF OPERATION 13
5.1. STANDARD ATS - OPEN TRANSITION 13
5.2. TEST MODES 14

Thomson Power Systems TSC 900 Specifications

General

Brand	Thomson Power Systems
Model	TSC 900
Category	Switch
Language	English
