Thomson Power Systems TSC 900 User Manual

TS 970 Transfer Switch
PM163 REV 0 20/02/05 31 Thomson Power Systems
10. CABLE TERMINAL INFORMATION
BASIC MODEL
TERMINAL RATING
CONNECTION TIGHTNESS
(In-lbs.)
QTY
PER PHASE
RANGE
TERMINAL
MOUNTING
SCREW
CABLE
CLAMP
TS 97xA-0100
1
#6-300 MCM
120
50
TS 97xA-0150
1
#6-300 MCM
120
120
TS 97xA-0200
1
#6-300 MCM
150
275
TS 97xA-0250
1
#6-300 MCM
150
275
TS 97xA-0400
1
2
2/0-500MCM
72
275
TS 97xA-0600
1
4
#4-600MCM
72
275
TS 97xA-0800
1
4
#4-600MCM
110
375
TS 97xA-1000
1
4
#4-600MCM
110
375
TS 97xA-1200
1
4
#4-600MCM
375
375
1. Optional terminal ratings are available in some models – Consult Thomson Power Systems.
2. For other model types not shown, contact Thomson Power Systems for further information.
