Thomson Power Systems TSC 900 User Manual

TS 970 Transfer Switch
PM163 REV 0 20/02/05 22 Thomson Power Systems
6. Withdraw the contactor to its disconnected position away from the busbars.
7. Align the extension rails (shown below) of a scissor lift into the power contactor
compartment.
8. Carefully pull the contactor onto the extension rails until it is completely withdrawn into the
rails.
9. As the contactor is placed onto the rails, safely lower and slide away the scissor lift.
10. Replace the power contactor then repeat steps 1 through 6 backwards to re-assemble the
new contactor.
STEPS 6-9
EXTENSION
RAILS
