21MD182T Version 1
MODULES
MAIN ETC009 T8-D5571J-MA1
56062190
CRT CRT T8-D5571J-CR1
56062090
FCB FCB T8-D5571J-SI1
56062270
KB KB T8-D5571J-KE1
56062120
I
IC001 M24C16-WBN6
20977300
IC201 TDA12020H/N1F00 UOC3 R=Y
56286960
IC300 STV9302B
60211650
IC601 TDA7266SA
35892060
IC801 TDA16846-2
60130550
IC860 TEA1520P
56043080
IR081 HRM533AA5100 (RIR)
21427450
T
Q001,805 2SD2012 3A 60V R=Y
56089530
Q002,850 2SC1815Y
20508030
Q102,201,202, BC847C SMD
90618810
281,602,900,
902,903
Q200,203 BC327-40
16000450
Q204,205 BC857A SMD
35849760
Q206,207,208, BC857C SMD
50854389
280,601,901
Q401 BC639
16001240
Q402 2SC5885
21428060
Q511,521,531 3DA4544 300V R=Y
56124540
Q512,522,532 BF422
16003090
Q513,523,533 BF423
16003110
Q801 2SK2996
35853760
D
D002,204,404, BZX79C5V6 0,50W
56036960
832
D003,306 BZX79C3V9 0,50W
16518650
D005,006,100, 1N4148
44009209
270,271,272,
281,300,305,
307,308,600,
807,810,850
D081 FB205 LED
35853860
D102 BZX79C33V 0,50W
35923130
D104,105,106 BA982-GS08 SMD
35849800
D280 BZX79C24V 0,50W
56039590
D304 BZX79C2V4 0,50W
16518640
D309,413,834 1N4001 50V/1A R=Y
36038140
D400 1N4002
11070780
D401,402,403, FR104
20569370
806
D405,833 1N4004
11073460
D500 BAV21
44044407
D511,521,531 LL4148 SMD
16012450
D801,802,803, RL255 R=Y
60145840
804
D805,860 1H8 R=Y
60129950
D824 RU3C
35853580
D831 BYW29-200 DIODE
16009090
D861,862,863, 1N4007
16008210
864
D865 FR102 1A 100V R=Y
56039650
D868 UF4004/16 400V
35861820
D900 BZX79C8V2 0,50W
35853620
D901,902,903, BZX79C6V2 1/2W 5%
35907120
905,907
D904,906 ZMM5.6 2% SMD
10291310
F
Z101 33M9HZ K9453D FOS
20992100
Z102 37M4HZ K3953-D100 R=Y FOS
35849850
Z200 24M576HZ
60141410
B
L001,002,003, 10UH 10%
60141070
004,101,200,
203,204,205,
207,208,209,
210
L202,211 10UH 10%
60134230
L412 150UH
35854600
L801 0,6UH 10%
60141090
L802,803,861 100UH
35854430
P
VR801 5K0 OHM
35854100
R
R313 1R0 OHM 1W
35854050
R321 1R5 5% OHM 2W
35853940
R403,405,409, 0R22 OHM 5% 0,50W R=Y W
56062000
418
R411 1K2 OHM 5% 2W
10134060
R420 1R0 OHM 5% 2W W
35005850
R500 1K5 OHM 5% 0,50W
10121880
R515,525,535 15K0 OHM 5% 3W
60132260
R611 0R22 OHM R% 2W R=Y
35854070
R801 4R7 OHM NTC R=Y W
35849450
R802,807 1M0 OHM 5% 0,50W W
56042190
R805,813 4M7 OHM 5% 0,50W W
35923310
R809 56K0 OHM 10% 2W
10151270
R824 22K0 OHM 5% 3W R=Y
35923290
R825 6R8 OHM 5% 2W
90576570
R834,836 0R22 OHM 5% 2W R=Y W
35923280
R837 8M2 OHM 5% 1W W
56044040
RT801 20R0 20% OHM PTC R=Y W
35883440
RT860 5R0 OHM NTC R=Y W
35923480
VR800 D15H471 VDR W
35849460
THOMSON
21DM182T
Chassis ETC009
PARTS LIST
LISTE PIECES DETACHEES
ERSATZTEILLISTE
LISTA PARTI DI RICAMBIO
LISTA DE PIEZAS DE REPUESTO
TV
A51ELD032X004 Version 1 : 21DM182T1
A51QDJ420X08 Version 2 : 21DM182T2
No copying, translation, modification on other use authorized. All rights reserved worldwide. • Tous droits de reproduction, de traduction, d'adaptation et d'exécution réservés pour tous les pays. • Sämtliche Urheberrechte an diesen Texten und Zeichnungen stehen uns zu. Nachdrucke,
Vervielfältigungen - auch auszugsweise - nur mit unserer vorherigen Zustimmung zulässig. Alle Rechte vorbehalten. • I diritti di riproduzione, di traduzione, e esecuzione sono riservati per tutti i paesi. • Derechos de reproduccion, de traduccion, de adaptacion y de ejecucion reservados para todos los paises.
For any requests, please contact THOMSON after sales europe area
Pour toutes précisions, contactez votre service apres vente local THOMSON service europe
Für weitere Auskünfte, wenden Sie sich bitte an die THOMSON sales europe Kundendienste
Per precisazioni, contattare l’assistenza tecnica THOMSON sales europe
Para cualquier pregunta, por favor contactar con el responsable de zona del servicio postventa de THOMSON sales europe
VERSION 1 09 / 2005
35997810
VERSION 2 03 / 2006
1/4
Lead Free
Sans Plomb
R=Y ohne blei
senza cavo
sin plomo
