21DC320T Version 1
MODULES
MAIN ETC009 T8-D5071J-MANHM
56287280
CRT CRT T8-D5071J-CRY
56287320
DPC DPC T8-D5071J-DPY
56287310
KB KB T8-D5071J-KEY
56287300
I
IC001 M24C16-WBN6
20977300
IC201 TDA12020H/N1F00 UOC3 R=Y
56286960
IC300 STV8172A
56012920
IC601 TDA7266SA
35892060
IC801 TDA16846-2
60130550
IC860 TEA1520P
56043080
IR081 HRM533AA5100 (RIR)
21427450
T
Q001 2SD2012
10221820
Q002,850 2SC1815Y
20508030
Q102,201,202, BC847C SMD
90618810
281,602,900,
902,903
Q200,203 BC327-40
16000450
Q204,205 BC857A SMD
35849760
Q206,207,208, BC857C SMD
50854389
280,601,901
Q401 BC639
16001240
Q402 3DD1556 R=Y
60130310
Q450 IRF630FP
25453960
Q511,521,531 3DA4544 300V R=Y
56124540
Q512,522,532 BF422
16003090
Q513,523,533 BF423
16003110
Q801 2SK3115
56045770
Q805 2SD2012 3A 60V R=Y
56089530
D
D002,204,404, BZX79C5V6 0,50W
56036960
832
D003,306 BZX79C3V9 0,50W
16518650
D005,006,100, 1N4148 R=Y
36028130
270,271,272,
281,300,305,
307,308,450,
600,807,810,
850
D081A FB205 LED
35853860
D102 BZX79C33V 0,50W
35923130
D104,105,106 BA982-GS08 SMD
35849800
D280 BZX79C24V 0,50W
56039590
D304 BZX79C2V4 0,50W
16518640
D309,413,834 1N4001
16008160
D400,401,402, FR104
20569370
403,422,806
D405,833 RGP30MT
10450220
D421 BY228 R=Y
36028680
D500 BAV21 R=Y
36030550
D511,521,531 LL4148 SMD
16012450
D801,802,803, RL255 R=Y
60145840
804
D805,860 1H8 R=Y
60129950
D824 RU3C
35853580
D831 BYW29-200 DIODE
16009090
D861,862,863, 1N4007 R=Y
55961730
864
D865 FR102 1A 100V R=Y
56039650
D868 UF4004/16 400V
35861820
D900,901,902, BZX79C6V2 1/2W 5%
35907120
903,905,907
D904,906 BZV55C5V6 SMD R=Y
56259900
D908 BZX79C8V2 0,50W
35853620
F
Z101 33M9HZ K9453D FOS
20992100
Z102 37M4HZ K3953-D100 R=Y FOS
35849850
Z200 24M576HZ
60141410
B
L001,002,003, 10UH 10%
60141070
004,101,200,
203,204,205,
207,208,209,
210
L202,211 10UH 10%
60134230
L411 300UH R=Y
35886170
L801 0,6UH 10%
60141090
L802,803,861 100UH
35854430
R
R313 1R0 OHM 1W
35854050
R321 1R5 5% OHM 2W
35853940
R403,405,409, 0R22 OHM 5% 0,50W R=Y
56062000
418
R420 13R3 OHM 5% 2W R=Y W
35853880
R451 3R9 OHM 2W
35853960
R500 1K5 OHM 5% 0,50W
10121880
R515,525,525, 15K0 OHM 5% 3W
60132260
535
R611 0R22 OHM R% 2W R=Y
35854070
R801 4R7 OHM NTC R=Y W
35849450
R802 1M0 OHM 5% 0,50W
56042190
R805,813 4M7 OHM 5% 0,50W
35923310
R809 56K0 OHM 10% 2W
10151270
R820,824 120R0 OHM 5% 2W R=Y
13001280
R825 6R8 OHM 5% 2W
90576570
R834,836 0R22 OHM 5% 2W R=Y W
35923280
R837 8M2 OHM 5% 1W W
56044040
RT801 20R0 20% OHM PTC R=Y W
35883440
THOMSON
21DC320T
Chassis ETC009
PARTS LIST
LISTE PIECES DETACHEES
ERSATZTEILLISTE
LISTA PARTI DI RICAMBIO
LISTA DE PIEZAS DE REPUESTO
TV
A51ERS357X440 Version 1 : 21DC320T1
A51ELD032X004
Version 2 : 21DC320T2
No copying, translation, modification on other use authorized. All rights reserved worldwide. • Tous droits de reproduction, de traduction, d'adaptation et d'exécution réservés pour tous les pays. • Sämtliche Urheberrechte an diesen Texten und Zeichnungen stehen uns zu. Nachdrucke,
Vervielfältigungen - auch auszugsweise - nur mit unserer vorherigen Zustimmung zulässig. Alle Rechte vorbehalten. • I diritti di riproduzione, di traduzione, e esecuzione sono riservati per tutti i paesi. • Derechos de reproduccion, de traduccion, de adaptacion y de ejecucion reservados para todos los paises.
For any requests, please contact THOMSON after sales europe area
Pour toutes précisions, contactez votre service apres vente local THOMSON service europe
Für weitere Auskünfte, wenden Sie sich bitte an die THOMSON sales europe Kundendienste
Per precisazioni, contattare l’assistenza tecnica THOMSON sales europe
Para cualquier pregunta, por favor contactar con el responsable de zona del servicio postventa de THOMSON sales europe
VERSION 1 05 / 2006
36117010
VERSION 2 00 / 0000
1/6
Lead Free
Sans Plomb
R=Y ohne blei
senza cavo
sin plomo
