MODULES

MAIN ETC009 T8-D5791J-MAN

56264650

CRT CRT T8-D5791J-CRY

56264640

FCB FCB T8-D5571J-SI1

56062270

KB KB T8-D5571J-KE1

56062120

IC001 M24C16-WBN6 R=Y

36103960

IC300 STV9302B R=Y

36160380

IC601 TDA7266SA R=Y

56062610

IC801 TDA16846-2 R=Y

56062590

IC860 TEA1520P R=Y

36137930

IR081 HRM533AA5100 (RIR) R=Y

36138120

Q001,805 2SD2012 3A 60V R=Y

56089530

Q002,850 2SC1815Y R=Y

56062400

Q102,201,202, BC847C SMD R=Y

56046360

281,900,902,

903

Q200,203 BC327-40 R=Y

36133640

Q204,205 BC857A SMD R=Y

56046380

Q206,207,208, BC857C SMD R=Y

36160340

280,601,602,

901

Q401 BC639 R=Y

56062280

Q402 2SC5885 R=Y

56062410

Q511,521,531 3DA4544 300V R=Y

56124540

Q512,522,532 BF422 R=Y

36160350

Q513,523,533 BF423 R=Y

36160360

Q801 2SK2996 R=Y

35853760

D002,204,404, BZX79C5V6 0,50W R=Y

36137540

832

D003,306 BZX79C3V9 0,50W R=Y

56036950

D005,006,100, 1N4148 R=Y

36028130

270,271,272,

281,300,305,

307,308,600,

807,810,850

D081A FB205 LED R=Y

56042240

D102 BZX79C33V 0,50W R=Y

35923130

D104,105,106 BA982-GS08 SMD R=Y

50130690

D280 BZX79C24V 0,50W R=Y

56039590

D304 BZX79C2V4 0,50W R=Y

16518640

D309,413,834 1N4001 50V/1A R=Y

36038140

D400,401,402, FR104 R=Y

20569370

403,806

D405,833 1N4004GP R=Y

36132770

D500 BAV21 R=Y

36030550

D511,521,531 LL4148 SMD R=Y

36103600

D801,802,803, RL255 R=Y

60145840

804

D805,860 1H8 R=Y

60129950

D824 RU3C R=Y

56339950

D830 RU3YX R=Y

56339970

D831 RU4YX R=Y

56339990

D861,862,863, 1N4007 R=Y

55961730

864

D865 FR102 1A 100V R=Y

56039650

D868 UF4004 400V R=Y

56043050

D900,901,902, BZX79C6V2 1/2W 5% R=Y

56036970

903,907

D904 BZV55C5V6 SMD R=Y

56259900

Z101 D9453D 33M9HZ FOS R=Y

36138050

Z102 37M4HZ K3953-D100 R=Y FOS

35849850

Z200 24M576HZ R=Y

56046290

L001,002,003, 10UH 10% R=Y

60141070

004,101,200,

203,204,205,

207,208,209,

210

L202,211 10UH 10% R=Y

60134230

L412 96UH 10% R=Y

56288380

L801 0,6UH 10% R=Y

56047260

L802,803,861 100UH R=Y

35854430

VR801 5K0 OHM R=Y

36160400

R313 1R0 OHM 1W R=Y

35854050

R321 1R5 5% OHM 2W R=Y

56402460

R403,405,409, 0R22 OHM 5% 0,50W R=Y W

56062000

418

R411 1K2 OHM 5% 2W R=Y

56062040

R420 1R0 OHM 5% 2W R=Y W

35005850

R500 1K5 OHM 20% 0,50W R=Y

36133060

R515,525,535 15K0 OHM 5% 3W R=Y

56308460

R611 0R22 OHM R% 2W R=Y

35854070

R801 4R7 OHM NTC R=Y W

35849450

R802,807 1M0 OHM 5% 0,50W R=Y W

56042190

R805,813 4M7 OHM 5% 0,50W R=Y W

35923310

R809 56K0 OHM 5% 2W R=Y

56297860

R824 22K0 OHM 5% 3W R=Y

35923290

R825 6R8 OHM 5% 2W R=Y

56402490

R834,836 0R22 OHM 5% 2W R=Y W

35923280

R837 8M2 OHM 5% 1W R=Y W

56044040

RT801 20R0 20% OHM PTC R=Y W

35883440

RT860 5R0 OHM NTC R=Y W

35923480

VR800 14D471K VDR R=Y

56289960

C206 150N0F 5% 100V R=Y

20467160

C401,404 1N0F 10% 500V R=Y

56044330

C403,409,412 390PF 10% 500V R=Y

56044350

C405 100N0F 5% 100V R=Y

36137490

C411 100U0F 20% 160V R=Y

56120370

C414 3N3F 10% 500V R=Y

56044340

C416 12N0F 5% 1K6V R=Y W

56045890

C420 10U0F 20% 160V R=Y

56043630

C421 300N0F 5% 250V R=Y W

56287060

C500 1N0F 10% 2K0V R=Y

56045620

C601,605 220NOF 20% 100V R=Y

56361160

C801,802 220N0F 20% 275V R=Y W

36031430

C803 100N0F 10% 400V R=Y

56045920

C804,805 4N7F 10% 200V R=Y W

56044940

C806 150U0F 20% 400V R=Y

36121700

C808,826,860 10N0F 10% 500V R=Y

56044360

C818 10N0F 20% 2KV R=Y

56046080

C819 560P0F 10% 2KV R=Y

56308770

C821 220P0F 5% 2KV R=Y W

56044700

C830 330P0F 5% 2KV R=Y

56368750

C833,834 470P0F 10% 400V R=Y W

56327930

No copying, translation, modification on other use authorized. All rights reserved worldwide. • Tous droits de reproduction, de traduction, d'adaptation et d'exécution réservés pour tous les pays. • Sämtliche Urheberrechte an diesen Texten und Zeichnungen stehen uns zu. Nachdrucke,

Vervielfältigungen - auch auszugsweise - nur mit unserer vorherigen Zustimmung zulässig. Alle Rechte vorbehalten. • I diritti di riproduzione, di traduzione, e esecuzione sono riservati per tutti i paesi. • Derechos de reproduccion, de traduccion, de adaptacion y de ejecucion reservados para todos los paises.

For any requests, please contact THOMSON after sales europe area

Pour toutes précisions, contactez votre service apres vente local THOMSON service europe

Für weitere Auskünfte, wenden Sie sich bitte an die THOMSON sales europe Kundendienste

Per precisazioni, contattare l’assistenza tecnica THOMSON sales europe

Para cualquier pregunta, por favor contactar con el responsable de zona del servicio postventa de THOMSON sales europe

VERSION 1 09 / 2006

36160330

VERSION 2 00 / 0000

1/2

SABA

F21182T

Chassis ETC009

PARTS LIST

LISTE PIECES DETACHEES

ERSATZTEILLISTE

LISTA PARTI DI RICAMBIO

LISTA DE PIEZAS DE REPUESTO

Lead Free

Sans Plomb

R=Y ohne blei

senza cavo

sin plomo
