I.
Product overview and connections
Connections
Connecting to the Network and the PC
The
ST2030 MGCP IP Phone has 2 RJ-45 ports that each support 10/100 Mbps full
duplex Ethernet connection to external devices
-
Network port and access port (one for PC
and one for LAN).
Network Port
(10/100
LAN)
Use the Ethernet cable to connect the LAN port to an Internet equipment, such as a hub,
switch. Or directly to the Network. In Power over Ethernet (PoE) office environment, the
IP phone can be powered from a switch via Ethernet cable, in which case the external
po
wer adaptor is not needed.
Headset
(optional)
Handset
AC Adapter
Computer
Extension Module
