Appendix F ’Network Settings (6RU and 10RU Devices)’ — Multiple Blade Centers
ViBE VS7000 261
User Manual
Multiple Blade Centers Configuration
Using stacking cables, it is possible to create groups of four 10RU blade
centers.
Figure F-2. Stacking of multiple blade centers
1
1.
The diagram and the associated caption originate from the HP Virtual Connect Cookbook (see full
reference in Section ’HP Documentation’ on page 264).
Table 1. Caption of the Stacking of multiple blade centers figure
Item Description
1 10 Gb Uplink
2 Switch Cross Connect
3 Enclosure 1
4 Enclosure 2
5 Enclosure 3
6 Enclosure 4
7 External 10Gb Stacking link
8 10 Gb Uplink
9 Internal Dual 10Gb Stacking links
