INSTALLATION & USE
2. Align mounting holes on the back of range hood with mounting screws on the wall.
Place range hood on the screws and fasten the screws.
3. Use the auxiliary screws provided to secure the range hood.
FIX THE AIR OUTLET
1.Use the sealing strip provided in the accessories bag and place it around the air
outlet joint cover by one circle and make sure there is no air leakage.
2.Using 4 screws provided to install the joint cover onto the range hood.
DUCT FIXING
Caution:To reduce the risk of tire,use metal ductwork only. (Metal duct should be able
to easily sourced from local hardware stores.)
1. Attach an adequate length of Φ7” round duct on the top the outlet adapter.
2.Secure the duct using fastener. Make sure the duct is tixed well on.
