FUEL SYSTEM
THOR MOTOR COACH | MADE TO FIT
31
4
• Remove fuel-soaked clothing immediately.
• Never use gasoline or diesel fuel as a cleaning solvent.
Fuel Transfer System Operation
TO FILL THE FUEL TRANSFER SYSTEM TANK
1. Remove the fuel ller cap and ll the tank with the
grade and type of fuel required by your equipment.
2. Replace the fuel cap when fueling is complete. When
replacing the fuel ll cap, be sure it seats squarely and
turn it rmly to lock it on the ll pipe neck.
TO TRANSFER FUEL TO ANOTHER VEHICLE
IMPORTANT! ere is a safety lock-out switch installed
on the Shore Cord Compartment that prevents the fuel
transfer pump from operating if this compartment door is
open. e Shore Cord Compartment Door must be closed
before using the fuel transfer system.
1. Ensure the fuel stored in the Fuel Transfer System is
compatible with the vehicle being fueled.
2. Ensure the Master Battery Disconnect Switch is ON.
3. Connect the ground wire from the motorhome to the
vehicle being fueled. e clip must connect to a metal
device of the vehicle being fueled, such as the frame.
4. Turn ON the fuel transfer pump switch. NOTE: One
Press of the switch turns the pump ON; two presses of
the switch turns the pump OFF.
5. Uncap the fuel tank cap on the vehicle being fueled
and place the fuel nozzle into the fuel tank port.
6. Squeeze the handle on the fuel nozzle to dispense fuel.
Be careful not to overll or spill fuel on either the
vehicle or ground.
7. Release the fuel dispensing handle when fueling is
complete.
8. Replace the fuel hose and nozzle into its storage bay.
9. Turn OFF the fuel transfer pump switch by pressing
twice on the switch.
10. Unclip the ground wire and place it in the storage bay.
EMERGENCY SHUT-OFF SWITCH
If the fuel dispensing nozzle becomes stuck or jammed in
the ON position, quickly turn o the fuel pump by pressing
TWICE on the pump switch.
Fuel Transfer System available on Class A toy hauler motorhomes
Fuel Pump Safety Lock-out Switch
Fuel Tank Inlet for Fuel Transfer System
