THORLABS GVS001 User Manual

Rev 22 Feb 2019
Page 9
Chapter 3 Installation & Initial Set Up
3.1.5 Heatsink Dimensions
Fig. 3.5 Heatsink Dimensions
3.1.6 Servo Driver Board Baseplate Dimensions
Fig. 3.6 Servo Driver Board Baseplate Dimensions
100.0 (3.94)
Drill & Tap M3 Thru
52.0 (2.05)
19.0 (0.75)
GHS002
97.0
(3.82)
11.20
(0.44)
10.40
(0.41)
3.0 (0.12)
24.0 (0.94)
25.0 (0.98)
85.1
44.2 (1.74)
7.2
(0.28)
1.6
(0.06)
24.2 (0.95)
M3 (3 Positions)
3.5 (0.14) DIA
25.5
(1.0)
45.88
(1.81)
66.0
(2.6)
74.0
(2.9)
5.0 (0.2)
9.07
(0.36)
45.0 (1.77)
33.0 (1.3)
15.0 (0.59)
3.0
(0.12)
4.8 (0.19)
3.0
(0.12)
6.0 Typ
(2.36)
54.0 (2.13)
Slot
52.5 (2.07)
74.8 (2.95)
3.3 (0.13)
6.5 (0.26)
All dimensions in mm (inches)
3.5 (0.14) DIA and
CSK to Suit
M3 Screw on Underside
(4 Positions)
