Page 6 18728-D01
Single- and Dual-Axis Scanning Galvo Systems for Small Beam Diameters
Chapter 3 Installation & Initial Set Up
3.1 Dimensions
3.1.1 Motor Assembly Dimensions
Fig. 3.1 Motor Dimensions
3.1.2 Mirror Dimensions
Fig. 3.2 Mirror Dimensions
0.09 (2.3)
0.06 (1.5)
1.22
(31.0)
Ø 0.9
(23.2)
1.49 (37.8)
0.87 (22.0)
Ø 0.5 (12.6)
Ø 0.1 (2.5)
all dimensions in inches (mm
)
0.57 (14.5)
0.34
(8.5)
0.04
(1.0)
0.04
(1.0)
0.39
(10.0)
0.32 (8.0)
X-Axis Mirror
Y-Axis Mirror
all dimensions in inches (mm
)
