Page 26 18728-D01
Single- and Dual-Axis Scanning Galvo Systems for Small Beam Diameters
Drive Electronics
* Using heat sink to keep temp <50°C (see Section 3.2.2.).
A.2 Associated Products
Parameter Value
Full Scale Bandwidth* 100 Hz Square wave,
250 Hz Sinewave
175 Hz Saw Tooth
175 Hz Triangular
Small Angle (±0.2°) Bandwidth* Typ. 1kHz with Sinewave
Small Angle Step Response 300 µs
Power Supply +/-15V to +/-18V dc
(1.25 A rms, 5A peak MAX)
Analog Signal Input Resistance 20K±1%Ω (Differential Input)
Position Signal Output Resistance: 1K±1%Ω
Analog Position Signal Input Range ±10V
Mechanical Position Signal Input Scale Factor switchable: 0.5V/°, 0.8V/° or 1.0V/°
Mechanical Position Signal Output Scale Factor 0.5V/°
Operating Temperature Range 0 ~ 40°C
Servo Board Size (L x W x H) 85 mm × 74 mm × 44 mm
(3.35” x 2.9” x 1.73”)
Product Name Part Number
2D Galvo System - Protected Silver Mirrors GVS002
1D Galvo System - Protected Silver Mirror GVS001
2D Galvo System - Protected Gold Mirrors GVS102
1D Galvo System - Protected Gold Mirror GVS101
2D Galvo System - Broadband E02 Mirrors GVS202
1D Galvo System - Broadband E02 Mirror GVS201
2D Galvo System - Dual Band High Power K13 Mirrors GVS302
1D Galvo System - Dual Band High Power K13 Mirror GVS301
Motor Assembly Heatsink GHS003(/M)
Galvo Power Supply GPS011
Servo Driver Card Cover GCE001
1D Galvo Cage System Mount GCM001
2D Galvo Cage System Mount GCM002 (/M)
Tip/Tilt Mount Adapter GTT001
