Rev 22 Feb 2019
Page 7
Chapter 3 Installation & Initial Set Up
3.1.3 Single Axis Mount Dimensions
Fig. 3.3 Single Axis Mounting Bracket Dimensions
0.55
(14.0)
0.55
(14.0)
all dimensions in inches (mm)
1.5 (38.0)
0.75 (19.0)
0.53
(13.5)
0.53
(13.5)
0.35 (9.0)
0.35 (9.0)
0.33 (8.5)
0.33 (8.5)
2 x Ø2.5 8.0
M3 x 0.5 -6H 6.0
2 x Ø 2.5 8.0
M3 x 0.5 -6H 6.0
M3 x 0.5 -6H
0.12
(3.0)
Ø 0.52 (13.2)
0.43 (11.0)
0.43
(11.0)
R 0.04 (1.0)
0.79
(20.0)
0.65
(16.5)
1.38
(35.0)
0.03 (0.75)
0.06 (1.5)
Qty 5 SLOTS
0.08 (2.0) Typ
0.08 (2.0) Typ
0.59 (15.0)
0.98
(25.0)
0.39
(10.0)
0.17
(4.3)
Ø 6.0 3.0
Ø 3.5 to SLOT
