Single- and Dual-Axis Scanning Galvo Systems for Large Beam Diameters
Notes
c The unit can operate beyond these limits with reduced performance until protections
trigger (250 Hz <10 sec). For a safe operation stay below 50 Hz 20Vpp sinewave
d Using heat sink to keep temp <35°C (see Section 3.1.2.).
e The settling time for the mirror to stop moving once the drive signal is removed.
Parameter Value
Drive Electronics
Full Travel Bandwidth
c
25Hz Square wave,
35 Hz Sinewave
Bandwidth (50% Full Travel)
d
65Hz Square wave,
130 Hz Sinewave
Small Angle (±0.2°) Bandwidth
d
1kHz
Small Angle Step Response
e
400 µs
Power Supply +/-15V to +/-18V dc
(1.25 A rms, 10A peak MAX)
Analog Signal Input Resistance 20k± 1% (Differential Input)
Position Signal Output Resistance 1K±1%
Analog Position Signal Input Range ±10V
Mechanical Position Signal Input Scale Factor switchable
0.5V/°, 0.8V/° or 1.0V/°
Mechanical Position Signal Output Scale Factor 0.5V/°
Operating Temperature Range 15 to 35 °C
Servo Board Size (L x W x H) 85 mm x 74 mm x 44 mm
(3.35” x 2.9” x 1.73”)
